VW T6, VW T5 Campervan Conversion CityVan (short wheelbase)

Campervan Conversion CityVan - not just for the city VW T5 / T6 Conversion CityVan
  • Leisure vehicle and campervan with extra space
  • Perfect for travelling with your dog or with lots of luggage
  • Rock and roll bed movable and removable
  • Narrow furniture unit with integrated cooler and sink
The VW T5 / VW T6 CityVan is the perfect leisure vehicle, campervan and camper for your weekend trip or with a campervan awning attached also ideal for an extended camping vacation. The wide rock and roll bed with its large, flat sleeping area is suitable for 3 people. The large space in the van offers plenty of space for pets and sports equipment.

Go to Rock and Roll Bed Variotech 3000 in our shop - Item no. 5040100 Go to Furniture Module CityVan kR in our shop - Item no. 10794 Go to Table in our shop - Item no. 50158 Go to Table in our Shop - Item no. 71177E Go to Roof wall cupboard for Reimo-Roof in our shop - Item no. 10797 Go to X-Trem Isolator in our shop - Item no. 50009 Go to Floor Plate decor ships floor in our shop - Item no. 1053832 Go to Rail-set Grizzly in our shop - Item no. 58200
  1. Rock and roll bed Variotech 3000®
    Three seats (size 14), movable and removable
    Total width: appr. 1305 mm, sleeping space: appr. 205 x 136 cm
    Integrated, retractable headrests, seat belts, rear upholstery height 46 cm under rear upholstery. Incl. Isofix holder for 2 child seats.
    Design: classic grey bi-colour
    Item no. 5040100
    Design: Austin T6
    Item no. 5040122
    Further fabrics and benches with heat exchanger can be found at Item no.M5040100 VW T6 / T5 bench movable size14.
    The seat bench can either be equipped with a front panel OR a drawer!
    Front Panel Item no. 5040180
    Drawer Item no. 5040190
    Each decor (panel or drawer): Basalt
    Optional: Isofix points (installed for 2 seats)
    Isofix – Item no. 58290M
  2. Rail set “Grizzly” for Variotech 3000®
    2 aluminium rails, silver anodised, length appr. 246 cm, one driving position
    Rail set Item no. 58200
  3. Floor plate 3 pieces
    Suitable for VW T6, VW T5 SWB, length appr. 246 cm
    Decor ship´s deck - Item no. 1053832
    Decor Quad – Item no. 1053831
  4. X-Trem Isolator 18 mm (not illustrated)
    Isolation underneath the bottom plate.
    X-Trem (one plate) – Item no. 50009
    Two plates are needed for short wheelbase, three plates for long wheelbase!
  5. Furniture module as finished part
    Elegant furniture part with cover flaps, prepared for installation of water system, compact sink and cool box. Wood decor: laminate anthracite.

    Item no. 10794
    Wood decor: high-gloss white
    Item no. 10794W
    Water system
    Installed in furniture module with sink, faucet, 13 l fresh-water-jerrican and 13 l sewage-water-jerrican, submersible pump
    Item no. 60004E
    Furniture Module Kit
    Wood decor: anthracite
    Item no.10794B
    Wood decor: high-gloss white
    Item no. 10794WB
    Water system
    Self-installation
    Item no. 60004
  6. Reimo compressor cooler box 26 liters (not illustrated)
    Slim cooler box, depth only 26 cm, temperature range +1°C to 10°C, W 570 x D 204 x H 360 mm, already integrated in furniture module
    Item no. 71177E
    Compressor cooler box for self-installation
    Item no. 71177
  7. Roof wall cupboard
    Prefabricated for extra storage space above rear seat bench
    Wood decor: anthracite
    Item no. 10800 for standard roof
    Item no. 10797 for pop-up roof superflat
    Item no. 10820 for Easy-Fit roof
    Wood decor: high-gloss white
    Item no. 10800W for standard roof
    Item no. 10797W for pop-up roof superflat
    Item no. 10820W for Easy-Fit roof
  8. Table
    Laminated decor slate, including wall holder and foldable table base. Tabletop appr. 85 x 47 cm
    Item no. 50158
  9. No Image:
    Diesel-Heater “Breeze”
    Small, compact heater mounted under the passenger seat. Capacity: 2,7 KW, fuel consumption max. 0.33 l/h, power requirement: 74-130 W, dimensions: L 355 x W 124 x H 126 mm
    Item no. 48129
    Digital control panel Item no. 48130
    Manual control panel Item no. 48131
    Mounting bracket underneath passenger seat Item no. 48132
    Porta Potti box
    Box for chemical toilet, HPL laminated anthracite, including upholstery (50mm), dimensions 390 x 425 x 348 mm
    Item no. 10698
    Porta Potti Qube 335 white
    Portable chemical toilet suitable for Porta Potti box
    Item no. 660101

Advantages of the Campervan Conversion Kit CityVan for VW T6 and T5

Advantages of the Conversion of CityVan: Compact furniture module
Compact furniture module
Offering space for a 13 l compressor cooler, drawer for cooker, storage compartment and 13 l fresh and waste water tank.
Advantages of the Conversion of CityVan: Additional Storage Space in Roof
Additional storage space in the roof
Spacious roof cupboard offering additional storage capacity.
Advantages of the Conversion of CityVan: Spacious trunk capacity
Spacious trunk capacity
The moveable and removable rock and roll bed allows for spacious, flexible trunk capacity.
Advantages of the Conversion of CityVan: Rear Storage easily accessible
Rear storage easily accessible
The storage space is easily accessible even if the seat bench is converted to the bed.
Advantages of the Conversion of CityVan: 3-person rock an roll bed
3-person rock and roll bed
Installed on rails – movable and removable. With integrate 3-point seat belt and retractable headrests.
Advantages of the Conversion of CityVan: Spacious Sleeping Area
Spacious sleeping area
The slim and elegant furniture module allows for a spacious, level sleeping space with a width of appr. 135 cm.
Advantages of the Conversion of CityVan: Flexible Loading
Flexible loading
When removing the front panel or drawer large luggage like skiers, snowboard or surfboard can easily be stored.
Advantages of the Conversion of CityVan: Comfortable seating area
Comfortable seating area
Create a comfortable seating area by simply turning the driver seat around.

Wooden decor and upholstery fabric for VW T6 and T5 CityVan

Wood decor anthracite
Standard: wooden decor anthracite
Wood decor white laminate
Option: wooden decor high-gloss white
Standard upholstery fabric Classic gray
Standard: upholstery fabric classic grey
upholstery fabric Austin
Option: upholstery fabric Austin

Looking for even more space within your campervan? Check out our campervan conversion kits for VW T6 and T5 long wheelbase:
Reimo CityVan for VW T5 & T6 LWB
Also available as ready to go campervan! Have a look at our brand new campervans with CityVan conversion:
Reimo Cityvan auf VW T6
Reimo Cityvan auf VW T5

Our Conversion-Partner in Germany, Austria and Switzerland

Campervan conversions – choosing, ordering and installing the right conversion kit!

Tips on how to order campervan conversions

The installation of most campervan conversions requires technical know-how, especially for mounting the rails / rock and roll bed as well as pop top roofs / high top roofs. To ensure that the installation complies with TÜV regulations Reimo only delivers to trained dealers.
The rails and campervan roof are being installed by a trained Reimo dealer but with sufficient technical skills the rest of the campervan conversion can be accomplished by yourself! The conversion kits developed and tested by Reimo simplify the campervan conversion.
If you have any questions concerning your campervan conversion, please send an email to our specialist!
Please order via one of our Reimo conversion dealers or the Reimo Megastores in Egelsbach or Bochum. The conversion parts will be delivered to the chosen dealer or Megastore. Just click on the map to find a Reimo conversion dealer near you to discuss your conversion plans. Please make sure that your conversion partner has seen your campervan at least once to ensure that the chosen conversion kit is suitable for your campervan conversion.
