Van Conversion Windows, Ford Transit Windows, Renault Trafic Windows, Fiat Ducato Windows, Mercedes Vito Windows, Mercedes Sprinter Windows
Retrofitting van conversion windows, do I need TÜV?You usually do not need TÜV for retrofitting van conversion windows. You must install the van conversion windows where the cunstruction policy allows it. This means, where the windows of the van would be. These places are clearly visible. It only becomes problematic if you damage bearing parts during sawing.
Installing Ford Transit windows, Renault Trafic windows, Fiat Ducato windows, Mercedes Vito windows, Mercedes Sprinter windowsFor the installation of Ford Transit windows, Renault Trafic windows, Fiat Ducato windows, Mercedes Sprinter windows or Mercedes Vito windows you only need the following tools:
Drilling machine, metal drill, jigsaw, rubber mallet and a suction cup with handle. Furthermore, a proper edge protection (Item No: 294541), cleaner (Item No: 29415), 2x adhesive kit (Item No: 294841) and adhesive tape to fix the window when inserting.
The preparations on the vehicle are quite clear. You just need to protect your vehicle from swarf and flying sparks. This means that you tape your vehicle in the area of the cutout and use a large amount of cover film inside the vehicle. Also draw the cutout dimension on the inside of the sheet. When this is done, drill 2 holes in each corner to be able to use the jigsaw "cleanly" and correctly. Now you follow the drawing with the jigsaw. The window cutout is done. Since you would like to use your vehicle for a long time, we recommend now the application of rust inhibitor at the cutting edges.
The fitting and gluing of van side windows e.g. the Ford Transit side window, Renault Trafic side windowNow is the turn for the final gluing of your van side windows. First, look at the cutting edge. If the inner and outer sheets are too too far apart, you can glue the two sides to create a narrow edge for the edge protection. From the middle of the window cut, press this all around onto the cut edge.
As soon as you are done with this, please clean the gluing area on the van side window and vehicle and let it dry for 15 minutes. Now apply the adhesive on the vehicle side. Place the van side window in the middle of the cutout and press it into the frame. Then fix it with tape. This is the best way to let your vehicle dry overnight with the fresh glue joints. After that, your vehicle is ready to use again.
Ford Tranist camper windows, Renault Trafic cameper windows, Fiat Ducato windows, Mercedes Vito windows, Mercedes Sprinter camper windows by CarbestVan conversion windows and van side windows by Carbest are available for different van types.
Available at Reimo:
- Mercedes Vito windows
- Ford Transit windows, Ford Transit camper windows, Ford Transit side window (sliding)
- Renault Trafic windows, Renault Trafic camper windows, Renault Trafic side window (fixed or sliding)
- Fiat Ducato windows (rearor sliding
- And sliding windows, fixed windows or rear windows for VW T5 and T6
All information and text inputs are without any gurantee and are based sloely on information that was available at the time of writing. We do not take any liability for the accurancy, completeness and timeliness of the information
